Linear 50 Fire Pit Kit
Modern and versatile Fire Pit Kit.
With its stylish design and ability to produce an elegant, elongated flame from a single ethanol or gas (NG/LP) burner, the Linear 50 Fire Pit Kit inspires fire designs for homes and intimate settings within commercial spaces.
Configure & Buy
Buy online and get it delivered to your door.Downloads
Model Specs
Technical information about the model.C&I Manual
Clearances & Installation information about the product.Burner Manual
Installation, operation and maintenance manual.Inspiration
Key Features
Sleek lines
A linear design and long flame makes it the epitome of style.
Trans-seasonal
Designed for year-round enjoyment, across the seasons, indoors and outside.
Complete design freedom
Bring your firepit ideas to life with easy integration into non-combustible surfaces including stone countertops, concrete surfaces, brick and tiled tops.
Focal point
Black glass charcoal creates a dramatic and stylish stage for a single long flamed indoor or outdoor fire pit that draws the eye.
Self-contained
Patio Fire Pit Kits are all completely self-contained, which means they’re easier to install than gas or wood-burning fireplaces.
Adjustable heat options
Choose the ideal heating level for your indoor or outdoor environment. Gas and Liquid Propane provide the highest heat, up to 65,000 BTU/h. Ethanol delivers comfortable warmth up to 20,433 BTU/h.
Quality Materials
Stainless steel and toughened glass ensure exceptional durability for indoor or outdoor installation.
Indoor or Outdoor
Choose from three different types of fuel to enjoy a warm fire anywhere, from the comforts of your home or in your outdoor space.
Smokeless flame
Enjoy the warmth and beauty of a clean-burning flame without the smoke, soot, or mess associated with a wood fire.
Everything you need
All the components you need to create a one-of-a-kind fire pit.
Three fuel choices
Select from three fuel types to suit your needs. Eco-friendly ethanol can be installed in just minutes and can be relocated without any limitations - indoors or out. Natural Gas delivers not only the lowest cost of operation but requires no refueling of any type, ever. Liquid Propane is readily available and powers with the simple push of a button.
Technical Specifications
Construction
- Weight 91.05lb [41.30kg]
- Model Dimensions in [mm] L 47.1in [1196mm] W 17in [431mm] H 12.1in [308mm]
- Application Indoor & Outdoor
- Materials Mild Steel & Toughened Glass
- Colours
Accessories
Includes everything you need to easily operate and protect your investment for many years to come.Three Flexible Fuel Options
- e-NRG Bioethanol
- Natural Gas
- Liquid Propane
- Fuel Comparison
Natural Gas | Liquid Propane | e-NRG Bioethanol | |
---|---|---|---|
|
Our Natural Gas (NG) systems provide not only the lowest cost of operation, they require no refuelling of any type, ever. Offering a high heat output and the flexibility to adjust the height of the flame as you desire, our Natural Gas burners feature a push button ignition and are UL/ULC Listed. | Fueled by readily available propane, our LP solutions feature up to 65,000 BTUs of heat output while requiring no costs for installation. Our LP burners are UL/ULC Listed, include a battery powered push button ignition and offer the flexibility to relocate your fire feature as needed. | Eco-friendly and plant-based, our ethanol fuel technology is suitable for indoor or outdoor installation. Our UL Listed ethanol fires are installed and operated in a matter of minutes. Completely selfcontained, ethanol provides the freedom to relocate your fire as desired without any limitations. |
Installation
Approved Use | Outdoor Only | Outdoor Only | Indoor or Outdoor |
UL/ULC Listed | UL/ULC | UL/ULC | UL |
Can Be Relocated | - | Yes | Yes |
Installation & Setup | Req. Certified Pumbles | Easy | Very Easy |
Electrical Required | None | None | None |
Operation
Heat Output (BTUs) | 65000 BTU/h | 65000 BTU/h | 15000 BTU/h |
Burn Time | Unlimited | 7-20 Hrs / Tank | 8-13 Hrs / Fill |
Operating Costs | $0.20 - $0.60 / Hour | $1.50 - $2.80 / Hour | $1.50 - $3.50 / Hour |
Adjustable Flame / Heat | Yes | Yes | - |
Fuel Source | Permanent Connection | External Tank | Self Contained Burner |
Fuel Availability | Plumbed | Ready Available | Delivered to your door |
Green / Eco-Friendly | - | - | Yes |
FAQ's
View AllIs Bioethanol easily obtainable?
Yes, you can have fuel delivered to public and private premises in many countries.
Is their heat output similar to a gas heater?
Burning bioethanol is similar to gas, but the room doesn't dry out like it does with gas - a more gentle, softer heat is created. Heat-wise, it depends on the models being compared. Some of our bioethanol burners output 15,000 BTU and can heat up to 60sqm of living space. Bioethanol is not, however, on an adjustable thermostat. Some may be turned up and down, but you can't control the room temperature in the same way as you do with gas on mains
Can I extinguish my ethanol fireplace before the fuel has burnt?
Yes, you can turn your EcoSmart Fire ethanol burner off at any given time, even if there is ethanol still left in the burner. It is recommended however, that you leave it to burn until it completely runs out. The shut off mechanism is there for security and safety for those times when you need to leave the house, as it is not safe to leave a fire unattended. You need to wait until your appliance cools to room temperature (60 minutes) before re-igniting, this is because hot vapours are a hazard and may cause a strong, initial ignition if the ethanol has not cooled long enough. This is also to ensure that the flame has been totally extinguished and that the appliance is safe to refuel if the amount of fuel in the burner at that time is insufficient for your next ignition / use.
How do I fill my ethanol fireplace?
With EcoSmart Fire’s proprietary tools and procedures, filling your ethanol fireplace with e-NRG bioethanol fuel is fast and easy.
Step 1: Remove the bottle nozzle cap and carefully insert into the filling point
Step 2: Push and hold the green button. The nozzle will automatically stop filling once the reservoir is full.
Step 3: Replace the nozzle cap.
You can view a step-by-step filling video.
Do I need to service my ethanol fireplace in any way?
Yes, normal maintenance and care is very important! Instructions are included in the Installation, Operating and Maintenance Manual supplied with your EcoSmart Fire product.
How do I clean my EcoSmart Fire ethanol burner?
Cleaning of the ethanol burner should be done only after you have used 50 litres of fuel or as soon as you notice a black residue forming around or on the burner. Before starting, make sure the burner is off, empty of ethanol, and at room temperature. Spray a multi-purpose cleaner on the surface of the burner and wipe with cloth, making sure to wipe in the direction of the grain. If material has fallen into the ethanol fireplace burner use a vacuum cleaner to remove debris through the burner opening. If your burner smells unusually strong after extensive use, remove the empty and room temperature burner from its surround and wash in hot, soapy water. Rinse thoroughly under running water and wait until the burner is completely dry before placing it back into its surround and reusing. View this video of the simple cleaning process here: https://youtu.be/VqHg9mXOc0U
Note: Stainless steel will rust or corrode over time if contamination or debris is not cleaned or removed immediately. When not in use, we recommend that you protect your ethanol fireplace from water damage or corrosion with a protective cover and the regular use of the burner lid included with your model.
Can EcoSmart Fires be installed everywhere?
Almost everywhere! EcoSmart Fires cannot be installed into small rooms that are less than our minimum room size which is burner specific. For all other installations, you must comply with our compulsory clearances and installation instructions. Approval from building authorities may be required prior to installation in your area. Please make sure you contact appropriate parties before installing your EcoSmart Fire.
What is bioethanol fuel?
Bioethanol (also known as methylated spirits or simply ethanol) is a form of renewable energy. It’s a clear, colourless liquid that’s commonly made from fermenting the sugar and starch components of plant by-products like sugarcane and grain crops.
